WinAPEX ET8103 LCD Auto Measure Multimeter AC/DC Voltage Current Capacitance Electric Field Resistance Meter RMS 6000 Counts

Rs.3,000
SKU: ET8103
Availability : In Stock Pre order Out of stock
People are viewing this right now
sold in last hours

Description

WinAPEX ET8103 LCD Auto Measure Multimeter Features:

  • Fully intelligent automatic measurement digital multimeter, the digital multimeter in the measurement will automatically recognize and automatically display no need for human operation.
  • 6000 counts and multifunction: display of 6000 counts and test of AC / DC voltage and current, resistance, capacitance.
  • Full protection: the body is equipped with a shockproof sleeve to prevent the instrument case from being damaged due to falling down, giving the body a full range of protection, and this protective cover can also be dustproof.
  • Easy to use and take: designed of compact and light, a bracket on the back for easy handling and placement.
  • Functions: LCD digital display, data hold, high voltage DC 1000V protection, low battery tips, auto power-off, live wire test, flashlight function.

WinAPEX ET8103 LCD Auto Measure Multimeter Specifications:

  • Material: PVC plastic
  • Color: black
  • Display: LCD display, 6000 counts
  • Power: 2 * AAA battery (not included)
  • DC voltage range: 6V/60V/600V/1000V
  • DC voltage resolution: 0.5%+4
  • AC voltage range: 6V/60V/600V/750V
  • AC voltage resolution: 0.8%+3
  • DC current range: 6A/10A
  • DC current resolution: 0.8%+8
  • AC current range: 6A/10A
  • AC current resolution: 1.0%+8
  • Resistance range: 600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ
  • Resistance resolution: 0.8%+5
  • Capacitance range: 60nF/600nF/6μF/60μF/600μF/6mF/60mF, 30mF, 30mF (<10mF value just for reference)
  • Capacitance resolution: 2.5%+60, 5.0%+10, 10%+5
  • True RMS: yes
  • NCV: AC non-contact electric field measurement
  • Flashlight function: yes
  • Buzzer: 0.1Ω-50Ω
  • Automatic: auto recognition according to measurment requirements
  • Continuity buzzer: 40Hz-1kHz (N only sine wave&triangular wave,
  • other>200Hz waveforms are for reference only)
  • Continuity test: about 0.6V
  • Data hold: yes
  • LCD backlight: yes
  • Low battery tips: yes
  • Auto shutdown: about 15 minutes
  • Environment: 18℃~28℃ (64℉~82℉) Relative humidity: ≤75>#br###LCD size: 50 * 33mm / 2.0 * 1.3in
  • Item size: 139 * 63 * 28.5mm / 5.5 * 2.5 * 1.1in
  • Item weight: 199g / 7.0ounce
  • Package size: 165 * 103 * 34mm / 6.5 * 4.1 * 1.3in
  • Package weight: 300g / 10.6ounce

Package list:

  • 1 * ET8103 Multimeter
  • 1 * Use Manual
