WeMos D1 Mini WIFI Development Board ESP8266 In Pakistan

Rs.637
SKU: 5878
Availability : In Stock Pre order Out of stock
People are viewing this right now
sold in last hours

Description

This IOT  Wemos D1 Mini WIFI Internet Of Things Development Board based on ESP8266 esp12e, Wemos d1 Mini is a WIFI board based on ESP-8266EX. 11 digital input/output pins, all pins have interrupt/PWM/I2C/one-wire supported(except D0) 1 analog input(3.3V max input) and a Micro USB connection. The Wemos D1 Mini is a great board to develop WiFi-based IoT Projects. It uses the popular ESP8266 Module for its IoT operations.

Specification and Features of Wemos D1 Mini:-

  1. 11 digital input/output pins, all pins have interrupt/pwm/I2C/one-wire
  2. supported(except D0)
  3. 1 analog input(3.2V max input)
  4. Micro USB connection
  5. Use BRT (Bias Resistor Transistor), easier into flash mode.
  6. 30% increase in radiating area, more stable.
  7. Dimensions : 35 x 26 x 8 (LxWxH) mm.
  8. Weight: 10 gm.
  9. Board Color : Blue
  10. Compatible with Arduino
  11. Compatible with NodeMCU
  12. Compatible with MicroPython

Package includes:

1 x  Wemos D1 Mini WIFI
