This is a variable power supply also called bench power supply, made by Tenma model no 72-7660, capable of producing Variable DC Volts on its output. Variable and regulated power supplies have integrated voltage regulators for output. This translates into the regulator making sure that the output voltage will always stay at the rated value of the power supply, irrespective of the current that the device is consuming. Because of the internal regulators, output voltages do not change due to any changes in input voltage.Each of your target devices may need a different amount of power (or DC voltage/ amperage) to function, meaning the power supply has to regulate the voltage to keep your device from overheating.
Specifications:
Parameters
Values
Input Voltage VAC
220V (With 110v transformers)
No. of Outputs
3
No. of Outlets
3
Output Current Max
10A
Output Current Min
0A
Output Voltage
30V
Output Voltage Max
31. 5V
Output Voltage Min
0V
Power Supply Output Type
Adjustable, Fixed
Device Height
115mm
Device Length
335mm
Device Width
205mm
Approximate shipment weight
~5Kg
Package includes:
1x Power Supply
1x Transformer 110V
1x Power Cable
Note: The transformer is included to make it compatible with the prevailing voltage standard.
