UT301A+ Infrared thermometer -32℃~420℃
The new UT301+ series is a durable and easy-to-use infrared thermometer with high accuracy/energy (95%)/repeatability. It has the adjustable high and low temperature visual/audible alarm, responding faster than 250ms, which can help you quickly find out anomalies. You can preset and save 5 sets of emissivity values, and quickly switch the emissivity according to different surfaces to get more accurate results. With the lock measurement, MAX/MIN/AVG/DIFF hold, and a tripod mount, UT301A+ is ideal for processes that require temperature monitoring. UT301A+ can be applied to power distribution/transportation equipment inspection, HVAC/equipment maintenance, vehicle troubleshooting, and more fields.
Features:
- 12:1 D:S ratio
- Adjustable emissivity 0.1~1.0
- ±1.5℃ temperature measurement accuracy
- User defined visual and audio alarm
- High contrast EBTN color display
- MAX/MIN/AVG/DIFF/Hold modes
- Single laser type
|
Specifications |
UT301A+ |
|
Temperature range |
-32℃~420℃ |
|
-25.6℉~788℉ |
|
|
Accuracy |
>0℃: ±1.5℃ or ±1.5%; ≤0℃: ±(1.5℃+0.1℃/℃) |
|
>32℉: ±3.0℉ or ±1.5%; ≤32℉: ±(3.0℉+0.1℉/℉) |
|
|
Repeatability |
0.7℃ or 0.7% (1.5℉ or 0.7%) |
|
D:S ratio |
12:1 (95%) |
|
Response time |
≤250ms (95% of reading) |
|
Emissivity |
0.1~1.0 (adjustable, stores 5 sets of preset values) |
|
Spectral response |
8um~14um |
|
Laser power |
< 1mW |
|
Features |
|
|
Auto power off |
√ |
|
Low battery indication |
√ |
|
LCD display |
Color EBTN |
|
High/low temperature LED alarm |
√ |
|
High/low temperature audible alarm |
√ |
|
Data hold |
√ |
|
℃/℉ selection |
√ |
|
MAX/MIN/AVG/DIFF mode |
√ |
|
Lock measurement |
√ |
|
Data storage |
- |
|
Scheduled measurement |
- |
|
Backlight |
√ |
|
Operating temperature |
0℃~50℃ (32℉~122℉) |
|
Storage temperature |
-20℃~60℃ (-4℉~140℉) |
|
Operating humidity |
<90% RH (non-condensing) |
|
Drop test |
1m |
|
Tripod mounting hole |
√ |
|
General Characteristics |
|
|
Power |
9V battery |
|
Display |
30mm x 30mm |
|
Product color |
Red and grey |
|
Product net weight |
204g |
|
Product size |
160mm x 74mm x 48mm |
|
Standard accessories |
Battery, carrying bag |
|
Standard individual packing |
Gift box, blister, English manual |
