UT658LOAD Digital USB Tester
The second generation UT658 series USB testers can inspect USB chargers, portable power sources, USB type A and C cables and other electronic charging devices. UT658 measures output voltage, current, energy, capacity, circuit equivalent resistance, D+ and D- voltages of USB data cables. This series is designed to be precise, reliable, stable, and portable. They are great tools for applications such as manufacturing verification, engineering testing, and Dyers.
|
Specification |
Description |
UT658LOAD |
|
Input & Output ports (Type A) |
|
√ |
|
Data/charging protocol |
|
2.0/3.0 |
|
Voltage range |
4~24VDC, resolution: 0.01V |
√ |
|
Current range (Type-A) |
0.05~3ADC, resolution: 0.01A |
√ |
|
Capacity |
0~99999mAh, resolution: 1mAh |
√ |
|
Energy |
0~1000Wh |
√ |
|
Circuit equivalent resistance measurement |
1~480Ω |
√ |
|
USB data cable voltage (D+, D-) |
0~3.3V |
√ |
|
Data storage |
10 sets |
√ |
|
Electrical load (UT658LOAD only) |
0.5A, 1A, 2A, 3A (Max power: 60W) |
√ |
|
Maximum recording time |
99h, 59min, 59sec; resolution: 1s |
√ |
|
Fast charge protocol (Type-A) |
QC 3.0 fast charge protocol |
√ |
|
General Characteristic’s |
||
|
Product color |
White |
|
|
Product net weight |
114.4g |
|
|
Product size |
122mm x 53mm x 27mm |
|
|
Standard individual packing |
Gift box, English manual |
|
