UNI-T UT658DUAL Type A + Type C Electric USB Safety Voltage Tester

Rs.3,248
SKU: UT658DUAL
Availability : In Stock Pre order Out of stock
People are viewing this right now
sold in last hours

Description

UT658 Series USB Testers

The second generation UT658 series USB testers can inspect USB chargers, portable power sources, USB type A and C cables, and other electronic charging devices. UT658 measures output voltage, current, energy, capacity, circuit equivalent resistance, and D+ and D- voltages of USB data cables. This series is designed to be precise, reliable, stable, and portable. They are great tools for applications such as manufacturing verification, engineering testing, and DIYers.

Features of UT658 Series USB Testers:

Certifications: CE, UKCA

  • Type-A/C interface
  • CE certification
  • 10 sets of data storage
  • Loop equivalent resistance measurement (1-480Ω)
  • The same screen shows voltage, current, power, capacity, etc.
  • Support fast charge protocol
Specifications of UT658DUAL USB Testers:

Specifications Description UT658DUAL
Input & Output ports (Type A) √
Input & Output ports (Type C) √
Data/charging protocol 2.0/(3.0/4.0)
Voltage range 4~24VDC, resolution: 0.01V √
Current range (Type-A) 0.05~3ADC, resolution: 0.01A √
Current range (Type-C) 0.05~5ADC, resolution: 0.01A √
Capacity 0~99999mAh, resolution: 1mAh √
Energy 0~1000Wh √
Circuit equivalent resistance measurement 1~480Ω √
USB data cable voltage (D+, D-) 0~3.3V √
Data storage 10 sets √
Maximum recording time 99h, 59min, 59sec; resolution: 1s √
Fast charge protocol (Type-A) QC 3.0 fast charge protocol √
Fast charge protocol (Type-C) QC 4.0 fast charge protocol √
General Characteristics
Product Color White
Product net weight UT658DUAL: 65.8g
Product size UT658DUAL: 93mm x 55mm x 13mm
