UT511 UNI T Digital Insulation Resistance Meter

Rs.25,200
SKU: UT511
Availability : In Stock Pre order Out of stock
People are viewing this right now
sold in last hours

Description

UT510 series testers can measure insulation resistance of large transformers, generators, high-voltage motors and more. UT510 series can also measure PI, DAR and other important specifications. Measured data can then be analyzed through PC software. UT513A can produce test voltage up to 5kV.

Features:

1. Large 9999 display with 30-segment analog bar graph2. PI/DAR measurements
3. Comparison, upper and lower limit functions
4. Continuous measurement mode
5. Auto power off
6. 18-group data storage
7. Backlight
8. Auto current discharge and high-voltage output alarm
9. Time measurement mode, auto measure within 15 minutes
10. Low battery and over range indications

Technical specifications:

Specifications 　 Range UT511
Insulation resistance (Ω) Test voltages 100V~1000V 0%~10>#/td###
100V 0.1MΩ~500MΩ ±(3%+5)
250V 0.5MΩ~2GΩ ±(3%+5)
500V 1MΩ~4GΩ ±(3%+5)
1000V 2MΩ~10GΩ ±(3%+5)
DC voltage (V) 1000V ±(2%+3)
AC voltage (V) 750V ±(2%+3)
Short-circuit current 　 <2mA
Low resistance (Ω) 0.1Ω~999.9Ω ±(1%+3)
Features
Auto range/Auto power off 　 √
Low battery indication 　 √
Data storage 　 18
Comparison measurement 　 √
Polarization index (PI) 　 √
Dielectric absorption ratio (DAR) 　 √
Analog bar graph 　 30
LCD backlight 　 √
Over-range warning 　 √
High voltage indication 　 √
Timing measurement Around 30 minutes √
General Characterisitics
Power 1.5V battery (LR14) x 8
Display 123mm x 58mm
Product color Red and grey
Product net weight 1.2kg
Product size 202mm x 155mm x 94mm
Standard accessories 2pcs of one plug test lead to one alligator clip (black and green), 1pcs of two plugs test lead to one alligator clip (red), batteries
Standard individual packing Gift box, tool box, English manual

Package:

1 x UT511 UNI T Digital Insulation Resistance Meter
