Description
UNI-T’s UT352 Sound Level (30~130dB) Meter has auto range and data storage function, with high/lower alarm, analogue outputs and condenser microphone.
Applications:
Noise control, quality control, health care and all kind of environment noise testing.
Features:
1. MAX/MIN modes
2. Auto power off (cancelable)
3. 63 sets data storage
4. AC/DC analog signal output
5. Over/under range indication
6. Data hold, LCD backlight
7. Simulated analog bar
8. A (ear)/C (machine) weighting modes
9. Manual/auto range selectable
10. Fast/slow response rate (fast: 125ms, slow: 1s)
11. Powered by batteries or external power source
Technical specifications:
| Specifications | Range | Best Accuracy |
| Model | UT352 | |
| Range | 30～80dB | ±1.5dB |
| 50～100dB | ±1.5dB | |
| 60～110dB | ±1.5dB | |
| 80～130dB | ±1.5dB | |
| Frequency | 31.5Hz～8000Hz | √ |
| Frequency Weighting | A&C | √ |
| Sample Rate | FAST: 8 Times/s | √ |
| SLOW: 1 Times/s | √ | |
| Features | ||
| Analogue Outputs | AC: 0.707Vrms full scale; Output impedance: around 600Ω | √ |
| DC: 2Vrms full scale; 10mV/dB; Output impedance: around 100Ω | √ | |
| Data Hold | √ | |
| Auto Power Off | √ | |
| Low Battery Indication | ≤4.8V | √ |
| MAX Mode | √ | |
| MIN Mode | √ | |
| Data Logging | 63 | |
| High Alarm | Display "OVER" | √ |
| Lower Alarm | Display "UNDER" | √ |
| LCD Backlight | √ | |
| Analog Bar Graph | 30～130dB | √ |
| General Characteristics | ||
| Power | 1.5V Batteries (LR6) X 4 | |
| LCD Size | 53mm X 41mm | |
| Product Color | Red and Grey | |
| Product Net Weight | 330g | |
| Product Size | 273mm X 70mm X 39mm | |
| Standard Accessories | Batteries, Windscreen, Leather Box | |
| Standard Individual Packing | Gift Box, English Manual | |
Package:
1 x UT352 UNI T Digital Sound Level Meter
UT352 UNI T Digital Sound Level Meter
Rs.31,920
