UT243 digital clamp meter is a stable, safe and reliable handheld power and harmonics clamp meter, which combines with a digital ammeter, power measurement, harmonic measurement. This UT-243 clamp multimeter is equipped with a powerful measurement and data processing software. This true RMS clamp meter is suitable for testing, calculating and displaying voltage, current, active power, power factor, phase angle, apparent power, reactive power, harmonic, electrical energy and frequency etc. From this tong tester meter, its harmonic measurement can be measured up to 20 times.Features Of UNI-T UT-243 Power And Harmonics Clamp Meter:
True RMS voltage/current measurement.
3-phase 3-wire, 3-phase 4-wire and single-phase 2-wire measurements.
10000 count LCD dual display.
Phase sequence detection.
Max/Min modes.
Auto range, auto power-off, backlight, low battery indication.
Equipped with USB interface and PC software CD.
Specifications Of Digital Clamp Meter Tong Meter UNI-T UT243:
AC Current: 50A/250A/1000A ±(2%+5)
AC Voltage: 150V/300V/600V ±(1.2%+5)
Frequency: 50Hz~60Hz
Active Power: 0.01KW-600KW ±(3%+5)
Apparent Power: 0.01KVAr-600KVAr ±(4%+5)
Reactive Power: 0.01KVA-600KVA ±(3%+5)
Power Factor: 0.3~1 ±(1%+2)
Phase Angle: 0° ~ 360° ±1°
Active Energy: 1~9999KWh ±(3%+5)
Display Count: 9999
Auto Range: Yes
Jaw Capacity: 50mm
True RMS: Yes
Auto Power Off: Yes
Low Battery Indication: Yes
Data Hold: Yes
MAX/MIN: Yes
Data Logging: 999
USB Interface: Yes
LCD Backlight: Yes
Full Icon Display: Yes
Single-Phrase 2-Wires: Yes
3-Phrase 3-Wires: Yes
3-Phrase 4-Wires: Yes
Phase Sequence Test: Yes
Harmonic Analysis: 1~20
Setup: Yes
Input Protection: Yes
Input Impedance for DCV: Around 5MOhm
Power: 1.5V Batteries(LR6)×4
LCD Size: 46mm X 42mm
Product Colour: Red and Grey
Product Net Weight: 601g
Product Size: 303mm X 112mm X 39mm
Package Includes:
1 x UNI Trend UT 243 Tong Tester
4 x Crocodile Clips
1 x Hard Case
4 x Test Leads
1 x USB Cable
