UT195 series are handheld industrial digital multimeters with IP65 and 2m drop proof. Compare with traditional multimeters, UT195's troubleshooting capability, resolution, and precision are improved to find issues related to motor drive, factory equipment maintenance, electrical distribution, and repair etc. It is exquisitely designed and easy to operate.
Applications:
It can be applied in mines, oilfields and other harsh environments.
Features:
1. IP65 rating, 2m drop proof, CAT III 1000V, CAT IV 600V
2. Large 6000-count LCD screen
3. True RMS
4. ACV 750V 5kHz bandwidth
5. Flashlight
6. Auto LCD backlight controlled by light sensor (can be turned off)
7. LoZ voltage test, for ghost voltage measurement
8. 20A current measurement (max 30 seconds)
9. 31 analog bar
Technical specification:
Specifications | Range | Best Accuracy |
Model | UT195E | |
DC voltage | 600mV ~ 1000V | ±(0.5%+3) |
AC voltage | 600mV ~ 1000V | ±(1.0%+3) |
LoZ ACV | 600.0V | ±(2.0%+3) |
DC current (A) | 600.0μA ~ 20A | ±(0.8%+3) |
AC current (A) | 600.0μA ~ 20A | ±(1.0%+3) |
Resistance (Ω) | 600.0Ω ~ 60.00MΩ | ±(0.8%+2) |
Capacitance | 6.000nF ~ 60.00mF | ±(3%+5) |
Frequency | 60.00Hz ~ 10.00MHz | ±(0.1%+4) |
Duty ratio | 0.1% ~ 99.9>#/td### | ±(2.0%+5) |
Features | ||
Display count | 6000 | |
Display interface (HTN) | Single display | |
Measurement sampling rate | times/s | 3 |
Analog bar sampling rate | times/s | 10 |
Analog bar | 31 bars | √ |
True RMS | √ | |
AC voltage frequency response | 45 ~ 400Hz | |
AC current frequency response | 45 ~ 400Hz | |
Diode/Continuity test | 3.5V | |
Auto/Manual range | √ | |
Auto power off | √ | |
Continuity buzzer | √ | |
Low battery indication | √ | |
Data hold | √ | |
MAX/MIN | √ | |
Function selection | √ | |
Flashlight | √ | |
Auto backlight | √ | |
Operating temperature | 0 °C ~40 °C | |
2m drop test | √ | |
Safety rating | IP65 | |
General Characteristics | ||
Power supply | 9V battery (6F22/6LR61) | |
LCD size | 66mm×51mm | |
Device color | Red and grey | |
Device weight | 450g | |
Device size | 206.5mm×95.5mm×61mm | |
Standard accessories | Test probes, battery, carrying bag | |
Standard individual packing | Gift box, blister, English manual (German, French, Spanish optional) |
Package:
- 1 x UT195E UNI T Industrial Waterproof Digital Multimeter
