UT18D UNI T Voltage And Continuity Tester

Rs.11,200
SKU: UT18D
Availability : In Stock Pre order Out of stock
People are viewing this right now
sold in last hours

Description

UT18 series are designed for testing AC/DC voltage, 3-phase voltage, phase sequence, continuity, and more. This series is categorized as CAT IV 600V and meets IP65 standard. These voltage testers are perfect tools for electricians to quickly measure voltage levels in all environments. This series should NOT be used with 110V electrical systems.

Features:

1. Auto power off, the conductor to be measured is greater than 12V2. Phase rotation test
3. Continuity test with buzzer and LED indication
4. Low battery indication and over voltage prompt
5. Flashlight
6. Test live voltage without batteries
7. Buzzer and silent modes available
8. Auto range
9. Polarity indication

Technical specifications:

Specifications Range UT18D
Voltage (V) 6V 5V±1V
12V 8V±1V
24V 18V±2V
50V 38V±4V
120V 94V±8V
230V 180V±14V
400V 325V±15V
690V 562V±24V
Phase rotation test 57Vac～400Vac (3 phase) √
Frequency: 50Hz~400Hz
Single lead (L2)
voltage detection		 Operating voltage: 100V~690V √
Frequency: 50Hz~400Hz
Continuity test Resistance: 0Ω~100kΩ (+50% accuracy) √
Beeper and LED light indication
RCD test Operating voltage: 230V (50Hz~400Hz) √
Polarity detection Positive & Negative √
Self-inspection All LED or LCD √
Features
Voltage indication 　 LCD
Exceed voltage Voltage range: 713V~788V √
Auto standby Standby current＜10μA √
Slient mode All range √
Work light 　 √
Low battery indication Around 2.5V √
LCD backlight 　 √
LCD display (voltage) 6V~690V ±(1.5%+5)
LCD display (Frequency) 40Hz~400Hz ±(3%+5)
IP65 　 √
General Characteristics
Power 1.5V battery (R03)×2
Display 73.5mm x 35.5mm
Product color Red and grey
Product net weight 280g
Product size (W x H x D) 272mm x 85mm x 31mm
Standard accessories Batteries
Standard individual packing Blister, English manual

Package:

1 x UT18D UNI T Voltage And Continuity Tester
