UT171C UNI T Industrial True RMS Digital Multimeter

Rs.67,200
SKU: UT171C
Availability : In Stock Pre order Out of stock
People are viewing this right now
sold in last hours

Description

 UT171 series are industrial grade multimeters used by professionals. Its built-in square wave output is useful for troubleshooting industrial control signals. Its LoZ (ACV) feature can be used to identify residual (ghost) voltage in large capacitors. UT171C’s OLED display is perfect for working in low temperatures down to -30°C.

Applications:
It is suitable for in design, research and repair.

Features:

1. AC+DC measurement 2. Peak hold
3. Rechargeable battery
4. VFC low-pass filtering
5. USB/Bluetooth communication

Technical specification:

Specifications Range UT171C
DC voltage (V) 1000V ±(0.025%+5)
AC voltage (V) 1000V ±(0.4%+40)
DC current (A) 10A ±(0.15%＋2)
AC current (A) 10A ±(0.75%＋5)
Resistance (Ω) 60MΩ ±(0.05%＋2)
Admittance (nS) 60nS ±(1%＋10)
Capacitance (F) 60mF ±(2.5%+40)
Frequency (Hz) 10Hz~10MHz ±(0.01%+5)
Temperature (°C)  -40°C~1000°C ±(1%+30)
Temperature (°F)  -40°F~1832°F ±(1.5%+50)
Features
Display count 　 60000
Auto/Manual range 　 √
Bandwidth (Hz) 100kHz √
4~20mA loop 0~100>#/td### √
LoZ (ACV) Around 3kΩ √
Diode Around 3V √
Continuity buzzer 　 √
Duty cycle 0.1%~99.9>#/td### √
NCV/Data hold/MAX/MIN 　 √
Relative mode 　 √
Data storage 　 9999
Display type 　 OLED
Analog bar graph 　 31
LCD backlight 　 √
Mis-plug alarm 　 √
Low battery indication 　 √
Auto power off 　 √
Input protection 　 √
Input impedance for DCV 　 √
Input impedance for DCV Around 1GΩ √
General Characteristics
Power 7.4V 2000mAh Li-ion battery
Display 70.6mm x 35.3mm
Product color Red and grey
Product net weight 384g
Product size 206mm x 95mm x 55mm
Standard accessories Batteries, test leads, point contact temperature probe,USB interface cable, power adaptor, PC software CD
Standard individual packing Gift box, carrying bag, English manual

Package:

  • 1 x UT171C UNI T Industrial True RMS Digital Multimeter
