UNI-T Industrial True RMS Digital Multimeter UT171B

Rs.58,240
SKU: UT171B
Availability : In Stock Pre order Out of stock
People are viewing this right now
sold in last hours

Description

The Digital multimeter of the UT171 series is with high precision, high reliability, high safety, an automatic range of characteristics, and now available in Pakistan. UT-171B meter is for accurate measurement of the voltage signal at 100 kHz broadband conditions, square wave signal, conductivity, and other signals. UT 171 B best electric multimeters, product chipsets the start mode VFC, the internal will go through a filter circuit in particular high-frequency interference filters, ensuring accurate measurement data. You can apply occasions with VFC frequency voltage from this true RMS meter, full-scale overload protection, and unique design, a more remarkable generation of practical electrical measurement instruments. UT-171B RMS multimeter can be used to detect various types of universities, foundry, telecommunications, manufacturing, oil, defense, electricity, electricity, circuits, electrical equipment, maintenance, and repair of the ideal tool.

Features Of Multimeter UNI-T UT171B:

Functions: measuring AC / DC current, AC / DC voltage, resistance, circuit on-off, conductivity, diode, capacitance, frequency, induced voltage, 4 - 20mA loopback test, temperature, etc.
True RMS VT - WLCD display: maximum display up to 60000 counts
Overload protection voltage between input terminal and grounding is 1000V
Auto shutdown and auto range function, power save and convenient
With data-storage, misoperation alarm function, and USB / Bluetooth interface configuration
Operation altitude: 0 - 2000m
For users in design, research, and repair needs
Built-in lithium-ion battery

Specifications Of Digital Multimeter UNI-T UT171B For Electronics:

DC Voltage: 600mV/6V/60V/600V/1000V
DC Voltage Accuracy: ±(0.025%+5)
AC Voltage: 600mV/6V/60V/600V/1000V
AC Voltage Accuracy: ±(0.4%+40)
DC Current: 600μA/6000μA/60mA/600mA/6A/10A ±(0.15%+10)
DC Current Accuracy: ±(0.15%+10)
AC Current: 600μA/6000μA/60mA/600mA/6A/10A ±(0.75%+20)
AC Current Accuracy:±(0.75%+20)
Resistance: 600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ ±(0.05%+2)
Resistance Accuracy:  ±(0.05%+2)
Capacitance: 6nF/60nF/600nF/6μF/60μF/600μF/6mF/60mF ±(2.5%+40)
Capacitance Accuracy: (2.5%+40)
Admittance: 60nS
Admittance Accuracy: (±2.5%+40)
Frequency: 10Hz~10MHz
Frequency Accuracy: ±(0.01%+5)
Temperature: -40°C~1000°C
Temperature Accuracy: ±(1%+3°C) only up to 230°C with standard accessory thermocouple
Display Count: 60000
Auto/Manual Range: Yes
True RMS: Yes
Bandwidth: 100kHz
AC+DC: Yes
4-20mA Loop: 0~100%
LoZ (AC): Around 3KΩ
Diode: Around 3V
Continuity Buzzer: Yes
Duty Cycle: Yes
VFC: Yes
NCV: Yes
Data Hold/MAX/MIN: Yes
Relative Mode: Yes
Peak Hold: Yes
Data Storage: 9999
USB Interface: Yes
EBNT Display: Yes
LCD Backlight: Yes
Analogue Bar Graph: 31
Rechargeable: Yes
Mis-plug Alarm: Yes
Low Battery Indication: Yes
Auto Power Off: Yes
Input Protection: Yes
Input Impedance for DCV: Around 10MΩ
Power: 7,4V 1800mAh Li-Ion Battery
LCD Size: 70.6mm x 35.3mm
Weight: 384g
Size: 206x95x55mm

Package Include:

  • 1 x UNI-T Industrial True RMS Digital Multimeter UT171B
  • 2 x Test Leads
  • 1 x Point Contact Temperature Probe
  • 1 x USB Interface Cable
  • 1 x CD with software
  • 1 x Power Adaptor
