UNI-T UT171A multimeter is an industrial-grade multimeter used by professionals. The UT-171A electronics RMS multimeter, Its built-in square wave output is useful for troubleshooting industrial control signals. UT 171 A true RMS meter, its LoZ (ACV) feature can be used to identify residual (ghost) voltage in large capacitors. This digital meter is with smart design and fast working features.
Features Of UNI-T Best RMS True Multimeter UT 171A:
Variable square wave signal output (frequency 0.5Hz ~4800Hz, low impedance) & 40000 / 60000 Counts / True RMS;
Measurement speed (5 times /s) is two times faster than the others & AC LoZ Voltage test;
AC / DC uA / mA / A current test & AC+DC measurement mode;
Resistance, electrical conductivity nS measurement & VFC household / industrial frequency conversion voltage test;
Electronic storage record 1000 & CAT III 1000V / CAT IV600V.
Specification Of DC/AC V/A Ohm/Hz Capacitance Tester UT-171A:
DC Voltage: 400mV/4V/40V/400V/1000V
DC Voltage Accuracy: ±(0.025%+5)
AC Voltage: 400mV/4V/40V/400V/1000V
AC Voltage: Accuracy: ±(0.4%+40)
DC Current: 400μA/4000μA/40mA/400mA/4A/10A
DC Current Accuracy: ±(0.15%+10)
AC Current: 400μA/4000μA/40mA/400mA/4A/10A
AC Current Accuracy: ±(0.75%+20)
Resistance: 400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ
Resistance Accuracy: ±(0.05%+2)
Capacitance: 4nF/40nF/400nF/4μF/40μF/400μF/4mF/40mF
Capacitance Accuracy: ±(2.5%+40)
Frequency: 10Hz~10MHz
Frequency Accuracy: ±(0.01%+5)
Display Count: 40000
Auto/Manual Range: Yes
True RMS: Yes
Bandwidth: 100kHz
VFC: Yes
Diode test: Yes
Continuity Buzzer: Yes
Duty Cycle: Yes
NCV: Yes
Data Hold/MAX/MIN: Yes
Relative Mode: Yes
Data Storage: 1000
USB Interface: Yes
LCD Display: Yes
LCD Backlight: Yes
Analogue Bar Graph: 31
Mis-plug Alarm: Yes
Low Battery Indication: Yes
Auto Power Off: Yes
Input Protection: Yes
Input Impedance for DCV: Around 10MΩ
Power: 6x 1,5V AAA
LCD Size: 70,6x49,5mm
Weight: 384g
Size: 206x95x55mm
Package includes:
- 1 x UNI-T UT171A Professional Intelligent Digital Multimeter
- 2 x Test Leads
- 1 x Point contact temperature probe
- 1 x USB interface cable
- 1 x PC software CD
- Batteries
Best Online Shopping website for UNI T Industrial Waterproof UT171A True RMS Digital Multimeter Pocket Size Avo Meter DC AC Voltage Current Meter Tester in cheap price in Karachi, Lahore, Islamabad, Rawalpindi, Peshawar, Multan, Quetta, Faisalabad and all over Pakistan.
