Description
UT139 series are CAT III 600V digital multimeters designed for electricians. Its NCV feature can effectively check electrical status through measuring EM field intensity. The new UT139E/S models include special features such as LoZ (ACV) for measuring‘ghost’ voltage. Its built-in 31-segment analog bar also gives electricians a better visual representation of measurement results. UT139S is built with black EBTN display and it is a perfect meter for working in dark environments.
Applications:
It can work in dark environment.
Features:
1. MAX/MIN/REL modes2. Data hold, LED backlight, auto power off
3. Full range protection (600V)
4. True RMS
5. NCV
6. Auto/manual ranges selectable
Technical specifications:
| Specifications | Range | UT139C |
| DC voltage (V) | 600V | ±(0.5%+2) |
| AC voltage (V) | 600V | ±(0.8%+3) |
| DC current (A) | 10A | ±(0.7%+2) |
| AC current (A) | 10A | ±(1%+3) |
| Resistance (Ω) | 60MΩ | ±(0.8%+2) |
| Capacitance (F) | 99.99mF | ±(4%+5) |
| Frequency (Hz) | 10Hz~10MHz | ±(0.1%+4) |
| Temperature (°C) | -40°C~1000°C | ±(1%+3) |
| Temperature (°F) | -40°F~1832°F | ±(1.5%+5) |
| Features | ||
| Display count | 6000 | |
| Auto range/Manual range /True RMS |
√ | |
| Bandwidth (Hz) | 45Hz~1kHz | |
| NCV/Continuity buzzer | √ | |
| Duty cycle | 0.1%~99.9>#/td### | √ |
| Diode | Around 3V | |
| General Characteristics | ||
| Power | 1.5V battery (R6) x 2 | |
| Display | 58mm x 36mm | |
| Product color | Red and grey | |
| Product net weight | 354g | |
| Product size | 170mm x 80mm x 48mm | |
| Standard accessories | Batteries, test leads, temperature probe | |
| Standard individual packing | Gift box, English manual | |
Package:
1 x UT139C UNI T True RMS Digital Multimeter
UT139C UNI T True RMS Digital Multimeter
Rs.11,760
