UNI-T UT10A automatic range digital multimeter is a portable laptop type 3 3/4. This UT 10A voltmeter digital meter completes function, stable performance, high precision, low power consumption, the structure is novel, safe and reliable. This voltmeter dc ac multimeter can be used to measure the ac/dc voltage, frequency, duty cycle, positive pressure drop and resistor, capacitor, diode on-off testing, is an ideal instrument to the masses of users.
Features Of Uni-t UT-10A Mini Digital Voltage Multimeter:
- Pocket size
- Automatic range finding
- AC DC voltage measurements
- Also measures capacitance & frequency
- Continuity & diode checks
- Thumb dial
- Integrated test leads
- Relative mode
- Auto power-off
Specifications Of UNI-T UT10A Pocket Palm Size Auto Range DC AC Digital Multimeter:
- DC Voltage Range: 400mV/4V/40V/300V
- DC Voltage Accuracy: ±(0.8%+1)
- AC Voltage Range: 4V/40V/300V
- AC Voltage Accuracy: ±(1.2%+3)
- Resistance Range: 400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ
- Resistance Accuracy: ±(1%+2)
- Capacitance Range: 4nF/40nF/400nF/4µF/40µF/200µF
- Capacitance Accuracy: ±(4%+3)
- Frequency Range: 10Hz/100kHz
- Frequency Accuracy: ±(0.5%+3)
- Auto Ranging: Yes
- Duty Cycle: 0.1%~99.9%
- Diode: Yes
- Continuity Buzzer: Yes
- Relative Mode: Yes
- Data Hold: Yes
- Full Icon Display: Yes
- Sleep Mode: Yes
- Low Battery Display: Yes
- Input Impedance for DC Voltage Measurement: Around 10MΩ
- Max. Display: 3999
- Power: 3V Button Battery (CR2032) (INCLUDED)
- LCD Size: 43 x 22mm
- Product Colour: Red and Grey
- Product Net Weight: 62g
- Product Size: 58 x 108 x 12mm
Packing Includes:
- 1 x UNI-T UT10A Digital LCD Palm Size Multimeter
- 1 x Test Lead
- 1 x User Manual
