UT890D UNI T UT 890D True RMS Digital Multimeter

Rs.4,256
SKU: UT890D
Availability : In Stock Pre order Out of stock
People are viewing this right now
sold in last hours

Description

A digital multimeter is a test tool used to measure two or more electrical values principally voltage (volts), current (amps) and resistance (ohms). UNI T True RMS DMM is a standard diagnostic tool for technicians in the electrical/electronic industries. The UNI-T UT890D 6000- count true RMS digital multimeters are designed with a large LCD display. UNI-T Digital Multimeter UT890 is ergonomic design, comfortable and solid. UT890D digital multimeter is a cheap accurate multimeter for very tight budgets.

Features:

  • True RMS measure for Current and Voltage. 6000 Counts display range.
  • It has an LCD backlight
  • REL function for Capacitance measuring. Minimum resolution rate 1pF, Maximum measuring range up to 6000uF.
  • Overload protection up to 600V for Capacitance, Resistance, Buzzer, Diode, and Frequency measuring.
  • High accurate frequency measuring function. Minimum resolution rate 0.001Hz, Unique
  • (MAX-MIN) value calculate function.
  • Frequency respond is (40Hz~1KHz) (Sine Wave, triangular wave)
  • Data hold, backlight, Auto-o. One 9V6F22 Battery Included.

Technical specifications:

1. Input Impedance for DC Voltage Measurement: 10M
2. Power supply:   9V6F22 Battery (Battery Included)
3. LCD screen dimension:   63mm*29mm
4. Safety grade:  CE / CAT.II 1000V / CAT.III 600V
5. External dimension:   186mm*91mm*39mm
6. DC voltage:

  • 600.0mV:  ±(0.5%+4)
  • 6.000V/60.00V/600.0V:  ±(0.5%+2)
  • 1000V: ±(0.7%+10)

7. AC voltage :

  • 6.000V/60.00V/600.0V: ±(0.8%+3)
  • Description Tags Reviews
  • 750V: ±(1.0%+10)

8. DC Current:

  • 60.00uA/6.000mA/60.00mA: ±(0.8%+8)
  • 600.0mA: ±(1.2%+5)
  • 20A: ±(2.0%+5)

9. AC Current:

  • 6.000mA/60.00mA:  ±(1.0%+12)
  • 600.0mA: ±(2.0%+3)
  • 20A: ±(3.0%+5)

10. Resistance:

  • 600.0Ω: ±(0.8%+5)
  • 6.000kΩ¸/60.00kΩ¸/600.0kΩ¸/6.000MΩ: ±(0.8%+3)
  • 60.00MΩ:± (1.0%+25)

11. Capacitance:

  • 6.000nF: ±(5.0%+35)
  • 60.00nF ~ 600.0uF: ±(2.5%+20)
  • 6000uF: ±(5%+10)

12. Frequency:

  • 9.999Hz ~ 9.999MHz: ±(0.1%+5)

13. Frequency Measuring range:

  • 10Hz~10MHz (Auto range)
  • ≤100kHz: 100mVRMS≤ Input ≤30VRMS,
  • >100kHz~1MHz: 200mVRMS ≤ Input ≤ 30VRMS,
  • >1MHz: 600mVRMS ≤ Input ≤ 30VRMS

Package:

  • 1 x UT890D UNI T UT 890D True RMS Digital Multimeter
