UT195 series are handheld industrial digital multimeters with IP65 and 2m drop proof. Compare with traditional multimeters, UT195's troubleshooting capability, resolution, and precision are improved to find issues related to motor drive, factory equipment maintenance, electrical distribution, and repair etc. It is exquisitely designed and easy to operate.
Applications:
It can be applied in mines, oilfields and other harsh environments.
Features:
UT195 series are handheld industrial digital multimeters with IP65 and 2m drop proof. It can be applied in mines, oilfields and other harsh environments. Compare with traditional multimeters, UT195's troubleshooting capability, resolution, and precision are improved to find issues related to motor drive, factory equipment maintenance, electrical distribution, and repair etc. It is exquisitely designed and easy to operate.
Technical specifications:
| Specifications | Range | UT195M |
| DC voltage (V) | 1000V | ±(0.5%+3) |
| AC voltage (V) | 1000V | ±(1.0%+3) |
| LoZ ACV | 600V | ±(2%+3) |
| DC current (A) | 20A | ±(0.8%+3) |
| AC current (A) | 20A | ±(1%+3) |
| Resistance (Ω) | 60MΩ | ±(0.8%+2) |
| Capacitance | 60mF | ±(3%+5) |
| Frequency | 60Hz~40MHz | ±(0.1%+4) |
| Duty cycle | 0.1%~99.9>#/td### | N/A |
| Temperature (°C) | -40°C~1000°C | ±(1.5%+4) |
| Temperature (°F) | -40°F~1832°F | ±(2%+5) |
| Features | ||
| Display count | 6000 | |
| Display interface (LCD) | Single | |
| Measurement sampling rate | times/s | 3 |
| True RMS | √ | |
| AC voltage frequency response | 45~1kHz | |
| AC current frequency response | 45~1kHz | |
| 3-phase motor sequence test | 600V | √ |
| Diode/Continuity test | 3V | |
| Auto/Manual range | √ | |
| Continuity buzzer | √ | |
| Low battery indication | √ | |
| Data hold/Auto power off | √ | |
| MAX/MIN | √ | |
| Function selection | √ | |
| Flashlight/Auto backlight | √ | |
| General Characteristics | ||
| Power | 9V battery | |
| LCD size | 66mm x 51mm | |
| Product color | Red and grey | |
| Product net weight | 437g | |
| Product size | 195mm x 95 mm x 58mm | |
| Standard accessories | Test probes, battery, carrying bag, point contact temperature probe | |
| Standard individual packing | Gift box, English manual (German, French, Spanish optional) | |
Package:
1 x UT195M UNI T True RMS Digital Multimeter
