Description
UNI-T UT70D Modern Digital Meter with advanced design. UNI–T UT70D is now available in Pakistan. Photoelectric separation guarentees absolutely secure galvanic isolation of multimeter from PC.LCD (79999), bar graph; I DC:80m/800m/8/10A. … frequency, AC voltage, DC voltage, capacitance, AC current, DC current, resistance, DC voltage measuring range.
Features:
- auto and manual ranging
- automatic power-off
- HOLD function
- impact resistant holster
- low battery indicator
- MIN/MAX/MEDIUM function
- REL function
- universal
Technical specification:
Specifications | Range | Best Accuracy |
Model | UT70D | |
DC Voltage (V) | 800mV/800mV/8V/80V/800V/1000V | ±(0.05%+10) |
AC Voltage (V) | 800mV/8V/80V/800V/1000V | ±(0.8%+20) |
DC Current (A) | 80mA/800mA/8A/10A | ±(0.2%+40) |
AC Current (A) | 80mA/800mA/8A/10A | ±(0.5%+40) |
Resistance (Ω) | 800Ω/8kΩ/80kΩ/800kΩ/8MΩ/80MΩ | ±(0.3%+40) |
Conductance | 80nS | ±(2%+120) |
Capacitance (F) | 1nF/10nF/100nF/1μF/10μF/100μF | ±(2%+3) |
Frequency | 1kHz/10kHz/100kHz/1MHz | ±(0.02%+1) |
Features | ||
Fused 10A Range | √ | |
Diode | √ | |
Continuity Buzzer | √ | |
True RMS | √ | |
Relative measurement | √ | |
Duty cycle | √ | |
Full Icon Display | √ | |
Sleep Mode | √ | |
Low Battery Display | √ | |
Input Impedance for DC Voltage Measurement | 10MΩ | √ |
Peak/Min/Max | √ | |
Data Hold | √ | |
Auto Data Hold | √ | |
Analog display | √ | |
Display Backlight | √ | |
RS232 | √ | |
Auto Ranging | √ | |
Max Display | 7999 (frequency measurement counts 99999) | √ |
LCD Size | 62×53mm | √ |
Analog Bar Graph | 41 | √ |
General Characteristic | ||
Power | 9V Battery (6F22) | |
LCD Size | 62mm×53mm | |
Product Color | Red and Grey | |
Product Net Weight | 600g (including holster) | |
Product Size | 195mm×90mm×40mm | |
Standard Accessories | Test Lead, Battery, Test Clip, RS232C Interface Cable, PC Software CD, Holster | |
Standard Packing | Gift Box, English Manual | |
Package:
1 x UT70D UNI T Multi Purpose Digital Multimeter
