UTP3300TFL series are economical single-channel linear DC power supplies with constant voltage/current feature.
Applications:
Electronics design, battery charging, electrical vehicle, research labs and education sectors.
Features:
1. Single channel, 3 digits display, shows voltage and current simultaneously2. Voltage display resolution: 100mV; current display resolution: 10mA
3. Voltage output: 0~30V consecutive and adjustable voltage
4. Auto voltage and current stabilization conversion, current limiting protection, undamaged for any external usage
Technical specifications:
Specifications | |
Model | UTP3313TFL |
Output voltage | 0~30V |
Output current | 0~3A |
Load regulation | CV≤1x10-4 +2mV, CC≤2x10-4 +3mA |
Ripple and noise | ≤0.3mVrms |
Output regulation resolution | CV: 100mV (typical), CC: 10mA (typical) |
Reliability | MTBF(e): ≥2000hrs |
Display mode | LED voltage and current dual display |
Feature | Auto conversion of constant voltage and current with current limit protection |
General Characteristics | |
Power | Input voltage: 110V AC/220V AC; frequency: 40Hz~60Hz |
Product color | White and grey |
Product net weight | 3kg |
Product size | 105mm x 160mm x 240mm |
Standard accessories | Power cord, output cables |
Standard individual packing | Carton box, English manual |
Package:
- 1 x UTP3313TFL UNI T DC Power Supply
- 1 x Power Cable
- 1 x User Manual
