14 Pin 12V Type 55.04 relay finder is widely suitable for DC or AC circuit switching in various automation devices. Also, this 14 pin relay is used in process control and communication equipment etc. 55.04 safety relay finder is characteristic of stable performance, high reliability, capable of making and breaking relatively large load current, easy in maintenance and inspection as well as long service life. The plug-in base of the relay is suitable for use with standard 8 and 11 pins socket.Features Of 55.04 12V General Purpose Industrial Power Electromagnetic Relay:
Small universal relay capable of the power switch.
Low power consumption.
Rugged Design.
Silver alloy contacts.
With the manual test button function.
With mechanical flag indicator.
Power Supply: AC(V) 6,12,24,48,60,110,220,240,380 50Hz: DC(V) 6,12,24,48,60,110,220.
Output Contacts rated 5A at 250 VAC or 30 VDC.
Four pole changeover contacts.
Socket mounted with a PYF14A/ PYF14A-E Socket.
Specifications Of General Purpose Electronic Power Finder Relay Type 55.04:
Type: 55.04
Contact type: 4Z
Contact capacity: AC 5A 250V, DC 5A 30V
Contact resistance: 50m
Insulation resistance: 100m
Dielectric strength: BOC 1000VAC, BCC 1500VAC
Coil nominal voltage: AC 6 to240V, DC 6 to 110V
Coil nominal power: AC 0.9VA to 1.2VA, DC 0.9W
Electrical life(OPS): 105
Mechanical life(OPS): 107
Operating temperature(c): -40~ 60
Weight(g): 35
Mounting: Printed-circuit board, Flange, Outlet
Applications:
Switch control for electric tools and a variety of motor.
Switch control for a variety of drying machine power control.
Switch control for controlling various lights.
Switch control for packaging machines, food processing equipment power control.
Package Includes:
1 x General Purpose Type 55.04 Relay Finder
