UT216C True RMS Digital Clamp Meter 600A UNI T

Rs.19,600
SKU: UT216C
Availability : In Stock Pre order Out of stock
People are viewing this right now
sold in last hours

Description

 UT216 series digital clamp meters are designed for measuring high frequency currents (up to 400Hz) in railways and aerospace, server rooms, IT systems, etc. Its double injection design gives users a more comfortable grip and enhanced durability.UT216’s 6000 count display also provides more precise readings for users.

Features:

1. True RMS2. Auto range, 3 times/s sampling rate
3. MAX/MIN/Relative modes
4. K-type temperature probe
5. Flashlight
6. 400Hz measurement
7. NCV, non-contact AC voltage testing
8. VFC, low pass filter
9. Zeroing function
10. Inrush current
11. Analog bar graph

Technical specification:

Package:

1 x UT216C True RMS Digital Clamp Meter 600A UNI T

Specifications Range UT216C
AC current (A) 600A ±(2.5%+5)
AC current frequency response 　 40~400Hz
DC current (A) 600A ±(2.5%+5)
AC voltage (V) 750V ±(1.2%+5)
AC voltage frequency response 　 40~400Hz
DC voltage (V) 1000V ±(0.8%+1)
Resistance (Ω) 60MΩ ±(1%+2)
Capacitance (F) 60mF ±(4%+5)
Frequency (Hz) 10Hz~1MHz ±(0.1%+4)
Temperature -40°C~1000°C ±(2%+5)
-40°F~1832°F ±(2%+10)
Features
Display count 　 6000
Auto range 　 √
Jaw opening 　 30mm
True RMS 　 √
Diode Around 3.0V √
V.F.C. 　 √
NCV 　 √
Data hold 　 √
Relative mode 　 √
MAX/MIN 　 √
LCD backlight 　 √
Inrush current 　 √
Analog bar graph 　 61
Flashlight 　 √
Auto power off 　 √
Continuity buzzer 　 √
Low battery indication ≤3.6V √
Input protection 　 √
Input impedance for DCV ≥10MΩ √
General Characteristics
Power 1.5V battery (R03) x 3
Display 38mm x 24mm
Product color Red and grey
Product net weight 231.7g
Product size 220mm x 75mm x 40mm
Standard accessories Batteries, test leads, point contact temperature probe
Standard individual packing Gift box, carrying bag, English manual
