Description
UT219 series is 600A true RMS professional clamp meter with CAT IV 600V rating. It is industrially designed with IP54 rating and able to withstand 2 meters drop test for measurement in harsh environments. This series is suitable for professional electricians, HVAC/R and motor service technicians.
Features:
1. LoZ input for ghost voltage measurement2. Flashlight and auto backlight
3. 3-phase motor sequence test
4. Temperature and μA measurements (flame sensor)
Technical specification:
| Specifications | Range | UT219M |
| AC current (A) | 600A | ±(1.8%+6) |
| AC voltage (V) | 600V | ±(1%+6) |
| DC voltage (V) | 600V | ±(0.6%+3) |
| LoZ ACV | 600V | ±(2.5%+6) |
| Resistance (Ω) | 60MΩ | ±(1%+3) |
| Capacitance (F) | 60mF | ±(4%+7) |
| Frequency (Hz) | 600Hz~40MHz | ±(0.1%+5) |
| Temperature | -40~1000℃ | ±(2%+5℃) |
| -40~1832℉ | ±(2%+9℉) | |
| Features | ||
| Display count | 6000 | |
| Auto/Manual range | √ | |
| Jaw opening | 33mm | |
| True RMS | √ | |
| AC current frequency response | 40Hz~400Hz | |
| AC voltage frequency response | 40Hz~400Hz | |
| 3-phase motor sequence test | 600V | √ |
| Diode test | 3V | |
| Measurement sampling rate | 3 times/s | |
| Display interface (LCD) | Single | |
| Auto power off/MAX/MIN | √ | |
| Low battery indication | √ | |
| Data hold (H)/Relative mode (REL) | √ | |
| ZERO mode | √ | |
| Function selection (SELECT) | √ | |
| Auto backlight/2m drop test | √ | |
| IP rating | IP54 | |
| Input impedance | ≥10MΩ | √ |
| General Characterisitics | ||
| Power | 1.5V battery (R03) x 3 | |
| Display | 35mm x 31mm | |
| Product color | Red and grey | |
| Product net weight | 310g | |
| Product size | 234.6mm x 82mm x 47mm | |
| Standard accessories | Test leads, batteries, carrying bag, PC software CD, point contact temperature probe | |
| Standard individual packing | Gift box, blister, English manual (German, French, Spanish optional) | |
Package:
1 x UT219M True RMS AC DC Clamp Meter 600A UNI T
UT219M True RMS AC DC Clamp Meter 600A UNI T
Rs.29,680
