TLV2217-33 TLV2217 33 Low Dropout Regulators In Pakistan EQUIVALENT OF LF33 / LF-33 / LF 33CLICK ME FOR DATASHEET
The TLV2217 family of low-dropout regulators offers a variety of fixed-voltage options that offer a maximum continuous input voltage of 16 V, making them more versatile than CMOS regulators. Utilizing a PNP pass element, these regulators are capable of sourcing 500 mA of current, with a specified maximum dropout of 500 mV (3.3-V and 2.5-V options), making these regulators ideal for low-voltage applications. Additionally, the TLV2217 regulators offer very tight
Features
Fixed 3.3-V Output
±1% Maximum Output Voltage Tolerance at TJ = 25°C
500-mV Maximum Dropout Voltage at 500 mA (3.3-V Option)
±2% Output Voltage Variation Across Load and Temperature
Internal Overcurrent Limiting
Internal Thermal-Overload Protection
Internal Overvoltage Protection
Applications
ESP8266 Power Supply
xbee power supply
Electronic Points of Sale
Medical, Health, and Fitness
Printers
Appliances and White Goods
TV Set-Top Boxes
APPLICATION CIRCUIT.
