Description
TIP42 TIP142C PNP Power Transistor is designed for general–purpose switching and amplifier applications.
Collector–Emitter Saturation Voltage —
VCE(sat) = 1.5 Vdc (Max) @ IC = 6.0 Adc
Collector–Emitter Sustaining Voltage —
VCEO(sus) = 60 Vdc (Min) — TIP41A, TIP42A
VCEO(sus) = 80 Vdc (Min) — TIP41B, TIP42B
VCEO(sus) = 100 Vdc (Min) — TIP41C, TIP42C
High Current Gain — Bandwidth Product
fT = 3.0 MHz (Min) @ IC = 500 mAdc
Compact TO–220 AB Package
Tip42 Tip142c Pnp Power Transistor
Rs.49
