Description
Type Designator: TIP102The material of Transistor is Si
Polarity: NPN
Maximum Collector Power Dissipation (Pc): 80 W
Maximum Collector-Base Voltage |Vcb|: 100 V
Maximum Collector-Emitter Voltage |Vce|: 100 V
Maximum Emitter-Base Voltage |Veb|: 5 V
Maximum Collector Current |Ic max|: 8 A
Max. Operating Junction Temperature (Tj): 150 °C
Transition Frequency (ft): 4 MHz
Forward Current Transfer Ratio (hFE), MIN: 1000
Package: TO220
TIP102 Datasheet
Tip102 Npn Transistor
Rs.98
