Stm32f4discovery Stm32f407vgt6 Arm Cortex-m4 32bit Mcu Core Development Board With Micro Usb Pin Module

Rs.2,058
SKU: 8988
Availability : In Stock Pre order Out of stock
People are viewing this right now

Description

Adaptive real-time accelerator (ART Accelerator) allowing 0-wait state execution from Flash memory, frequency up to 168 MHz, memory protection unit, 210 DMIPS/ 1.25 DMIPS/MHz (Dhrystone 2.1), and DSP instructions Memories.
Features:

Real-time adaptive accelerator Allowing 0-wait state execution
Flash memory frequency up to 168 MHz
Memory Protection Unit, 210 DMIPS /
1.25 DMIPS / MHz (Dhrystone 2.1) and DSP

RAM

Flexible static memory controller
Compatible with Compact Flash, SRAM,
Memories of PSRAM and NAND
Parallel LCD interface, 8080/6800 modes
Clock management, restart and supply
-Application of 3.6 V to 1.8 V and I / O
-POR, PDR, PVD and BOR
-Crystal oscillator from 4 to 26 MHz
-16 MHz internal factory remote control (1%
Precision)
-32 kHz Oscillator for RTC with calibration
-Internal remote control of 32 Khz with calibration
Low operating power
-Mods of sleep, stop and wait
-Supply VBAT for RTC, backup of 20 × 32 bits
Records + optional backup SRAM of 4 KB
3 12-bit converters, 2.4 MSPS A / D: up to 24
Channels and 7.2 MSPS in triple interleaved

Mode

Converters 2 12 bits D / A
General use DMA: 16 DMA lathes
Controller with FIFOs and burst support
Up to 17 timers: Up to 12 16 bits and two 32-
Bit timers up to 168 MHz, each with up to 4
IC / OC / PWM or pulse and quadrature counter
(Incremental) Encoder input

Debbuing Mode:
Depuration of serial cable (SWD) and JTAG
The Interface:

-Cortex-M4 trace embedded microcell ™
LQFP64 (10 × 10mm)
LQFP100 (14x14mm)

Clock

2 CAN interfaces (active 2.0B)
-SDIO Interface
Advanced connectivity
-High speed USB 2.0 device / host / OTG
Controller with physical layer on chip
-USB 2.0 high speed / full speed
Device / host / OTG driver with dedicated
DMA, physical layer of high speed on chip and ULPI
-Ethernet 10/100 with dedicated DMA:
Compatible with IEEE 1588v2 hardware, MII / RMII
Parallel Camera Interface from 8 to 14 bits up
54 Mbytes / s
Real random number generator
Calculation unit CRC
96-bit unique identification
RTC: Subsecond accuracy, hardware calendar

WLCSP90

LQFP176 (24 × 24mm)
Up to 140 I / O ports with interruption capability
-Up to 136 e / s fast up to 84 MHz
-Up to 138 5 V-tolerant I / O
Up to 15 communication interfaces
-A 3 × I2C interfaces (SMBus / PMBus)
-Up to 4 USARTs / 2 UARTs (10.5 Mbit / s, ISO
Interface 7816, LIN, IrDA, modem control)
-Up to 3 SPIs (42 Mbits / s), 2 with muxed
Full-duplex I2S to achieve audio
Accuracy by internal or external audio PLL

Package Include:
1XSTM32F4discovery
