Stepper Motor Driver Signal generator module is a pulse generation module, supplies the control signal to the stepper driver.To control the stepper motor, it must be equipped with a drive.
This simple controller + stepper motor + DC power supply can be composed of a simple set of control platforms.
The controller has high 5.4k-160khz, middle 540-16.6khz, a low 80-2.4khz total of 3 kinds of low-frequency signal that can be used to select the jumper.
It can produce a pulse signal, can also produce a PWM signal, can choose the jumper.
The frequency of measurement: PUL and common cathode end
Different stepper driver may mark different name
EN=ENA=FREE Enable
PUL=PULS=CLK Pulse
DIR=CW=CWW Direction
Common anode Connection method (B)
EN+ PUL+ DIR+ connect together to com+。
EN- connect EN
PUL- connect CLK
DIR- connect DIR
Common cathode Connection method (B)
EN- PUL- DIR- connect together to com-。
EN+ connect EN
PUL+ connect CLK
DIR+ connect DIR
Buy Stepper Motor Driver Signal Generator 8V To 24V at Pakistan's Best Online Store at cheap price. Here you get a wide range of Stepper motor drivers. We Deliver in Gujranwala, Karachi, Lahore, Islamabad, Rawalpindi, Multan, Quetta, Faisalabad and all over Pakistan.
Package Include:
1x Stepper Motor Driver Signal Generator 8V To 24V
