Solid State Relay Ssr Module 4 Channel G3mb-202p

Rs.1,176
SKU: 6761
Availability : In Stock Pre order Out of stock
People are viewing this right now
sold in last hours

Description

Solid State Relay SSR Module 4 Channel G3MB-202P Solid state relays consist of a pair of triacs driven and isolated from the control by a photocoupler. They are perfectly suited for driving loads such as motors, heaters, solenoids, valves, and fans in maximum safety and with total decoupling between the two stages with guaranteed insulation up to 1.5KVac.

With this module equipped with four OMRON G3MB-202P relays it is possible to drive important loads with an absorption up to 2A.

The input and output terminals of the G3MB-202P are electrically isolated, which allows you to control very high currents with very small input signals.

It can be widely used in machine tools, cnc, IR stations, and wherever it is necessary to drive important loads. The very small footprint and the rapid assembly and connection using the screw terminal blocks on the pcb, make it a very valid and easy to use product.

Technical specifications:

  • Permissible output voltage: 240VAC
  • Maximum controllable current: 4 channels of 2A each.
  • Resistive fuse protected output: 2A maximum
  • Supply voltage: 5Vdc
  • Absorbed current: ≤160mA
  • Activation voltage: 3.3 ~ 5Vdc
  • Activation current: 2mA
  • Status led for each channel
  • Dimensions 57 x 55 x 25h mm

Connection method:

Input:

DC +: + 5Vdc

DC-: GND

CH1: channel 1 activation signal

CH2: channel 2 activation signal

CH3: channel 3 activation signal

CH4: channel 4 activation signal

Output:

Four two-contact terminal blocks for each output
