Solid State Relay 40A is an electronic switching device that switches on or off when a small external voltage is applied across its control terminals. Solid State Relay 40A consists of a sensor which response to an appropriate input (control signal). Solid State Relay 40A which switches power to the load circuitry, and a coupling mechanism to enable the control signal to activate this switch without mechanical parts. Specifications:
Model
SSR-40VA
Load current
40A
Load voltage
24-380VAC
Control voltage
1MΩ 1/2W / 220V AC
On state leakage current
≤2mA
Off-state time
≤10mS
Dielectric strength
2500VAC
Insulation resistance
1000MΩ500VDC
Ambient temperature
-30°c ~ 75°c
Mounting method
bolting
Indicator
No Indicator
Weight
135g
Model number
SSR-VA series
Rated input control voltage
Variable resistor
Input resistance
470KΩ 2W potentiometer
Wattage of VR
1/4 W min
Pick-up or drop-out time
10ms max
Control type
Phase control
Input-ON indication
LED
On-state leakage current
2mA max
On-state voltage drop at Imax
1.5Vac
Matched heat sink
≤40A: FHSI01-50, ≤60A: FHSI02-50, ≤120A: FHSI03-100
Matched thermal grease
HZ-KS101
Dielectric strength
2500VAC 50/60Hz for 1 minute
Insulation resistance
500 MΩ min at 500 VDC
External dimensions
62x45x23.5mm
Terminals
Screw
Operational temperature
-30 to 75℃
Operational humidity
95% max no condensation
Solid State Relay 40A Advantages:
Special general circuit design for large current, high-quality circuit board
Use copper terminals for big current, increase the safety of connection and use
Use a pure aluminum base plate, with better performance and long life.
Hign-end flame-retardant PV plastic, thermostability can up to 70-80 degrees.
Buy Solid State Relay 40A at Pakistan's Best Online Store at cheap price. Here you get the best SSR modules. We Deliver in Gujranwala, Karachi, Lahore, Islamabad, Rawalpindi, Multan, Quetta, Faisalabad and all Over Pakistan
Package Includes:
1 x SSR-40VA solid state relay
