SIM800A BOARD 1800/1900 MHZ GSM GPRS MODULE

Rs.2,250
SKU: SIM800A
Availability : In Stock Pre order Out of stock
People are viewing this right now

Description

The SIM800A Quad-Band GSM/GPRS Module with RS232 Interface is a complete Quad-band GSM/GPRS solution in an LGA(Land grid array) type which can be embedded in the customer applications. SIM800A support Quad-band 850/900/1800/1900 MHz, it can transmit Voice, SMS and data information with low power consumption.

With a tiny size of 100 x 53 x 15 mm, it can fit into slim and compact demands of custom design. Featuring and Embedded AT, it allows total cost savings and fast time-to-market for customer applications.

The SIM800A modem has a SIM800A GSM chip and RS232 interface while enables easy connection with the computer or laptop using the USB to the Serial connector or to the micro-controller using the RS232 to TTL converter. Once you connect the SIM800A modem using the USB to RS232 connector, you need to find the correct COM port from the Device Manager of the USB to Serial Adapter.

Then you can open Putty or any other terminal software and open a connection to that COM port at 9600 baud rate, which is the default baud rate of this modem. Once a serial connection is open through the computer or your micro-controller you can start sending the AT commands. When you send AT commands for example “AT\r” you should receive back a reply from the SIM800A modem saying “OK” or other response depending on the command sent.

SIM800A BOARD Features:

  • Quad-band 850/900/1800/1900MHz.
  • GPRS class 2/10.
  • Control via AT commands (3GPP TS 27.007, 27.005 and SIMCOM enhanced AT command set).
  • High-Quality Product (Not hobby grade).
  • 5V interface for direct communication with MCU kit.
  • Configurable baud rate.
  • Built-in SIM Card holder.
  • Built-in Network Status LED.
  • Inbuilt Powerful TCP/IP protocol stack for internet data transfer over GPRS.
  • Low power.

SIM800A GSM GPRS MODULE Specifications:

  • Arduino 51 STM32 AVR MCU compatible
  • Prototype expand
  • The frequency is 850/900/1800/1900 MHz
  • Power supply range: voltage is 5-12V; current is 1A or more (the current is very important).
  • Operating temperature range: -40 °C to +85 °C
  • Communication interface: The TTL level serial interface compatible 2.85/3.3/5V
  • LED: Two led, the Net led and the RING led.
  • Size: 48*50mm
  • SIMCARD: micro SIMCARD holder

Package Includes:

1 x SIM800A BOARD 1800/1900 MHZ GSM GPRS MODULE

1 x Antena

1 x Wire
