Shaft Guide Mill RepRap Rod Holder 3D Printer Linear Rail Support CNC SK8 8mm in PakistanUsable with any 8mm linear guide, you can simply slide the rail through, then tighten the clamp screw at the top to fix it in place. Then use up to 6mm diameter bolts to attach them. If you need to disassemble or otherwise repair your machine. It`s easy to open up the clamp and remove the rail. It has high friction resistance can get high precision rotating in the smooth movement.
Shaft Guide Mill RepRap Rod Holder 3D Printer Linear Rail Support CNC SK8 8mm
Unit Designation
dr
Main Dimensions (mm)
Locking bolts
Mounting bolts
Weight (kg)
h
E
W
L
F
G
P
B
S
SK8
8
20
21
42
14
32.8
6
18
32
5.5
M4
M5
0.024
SK10
10
20
21
42
14
32.8
6
18
32
5.5
M4
M5
0.024
SK12
12
23
21
42
14
37.5
6
20
32
5.5
M4
M5
0.030
SK13
13
23
21
42
14
37.5
6
20
32
5.5
M4
M5
0.030
SK16
16
27
24
48
16
44
8
25
38
5.5
M4
M5
0.040
SK20
20
31
30
60
20
51
10
30
45
6.6
M5
M6
0.070
SK25
25
35
35
70
24
60
12
38
56
6.6
M6
M6
0.130
SK30
30
42
42
84
28
70
12
44
64
9
M6
MS
0.180
SK35
35
50
49
98
32
82
15
50
74
11
M8
M10
0.270
SK40
40
60
57
114
36
96
15
60
90
11
M8
M10
0.420
SK50
50
70
63
126
40
120
18
74
100
14
M12
M12
0.750
SK60
60
80
74
148
45
136
18
90
120
14
M12
M12
1.100
