PX-338 is original good soldering iron which has an automatically controlled heater, it's mean this good soldering iron will maintain its heat at a specific point.Automatically controls the amount of heat generated by the heat load applied to the iron tip and keeps it at a constant temperature. Quick heat recovery is possible thanks to the high power ceramic heater. The heat-insulating structure and the rubber grip cover block heat conduction to the hand. The PX-2RT series is a long-life soldering iron tip.
Specifications:
Model
PX-335
PX-338
PX-342
Voltage
110-120V, 220-240V AC 50/60Hz
Power Consumption
110-120V model
90-130W
220-240V model
85-120W
75-110W
Temperature Setting Range
350°C
380°C
420°C
Ripple temperature
±5˚C (unloaded)
Insulation Resistance
Over 100MΩ (500V DC)
Heater
Ceramic Heater
Power Cord Length
1.5m
Length
220mm
Weight
70g
Accessories
Soldering Iron Tip (PX-2RT-B)
*The length does not include the cord bushing. The weight does not include the cord.
The heater is automatically controlled.
model
PX-335
PX-338
PX-342
Rated voltage
110-120V, 220-240V AC 50 / 60Hz
power consumption
85W
Temperature range
350
380
420
error
No load ± 5
Insulation resistance
100M or more (500V DC)
Heater
Ceramic heater
Power cord length
1.5m
full length
220mm
weight
70g
Standard tip
Tip (PX-2RT-B)
does not contain the full-length handle of the power connector, weight does not include the power cord.
