Piezo Active Buzzer 3V To 12V

Rs.34
SKU: 6150
Availability : In Stock Pre order Out of stock
People are viewing this right now
sold in last hours

Description

This 3V To 12V Piezo Active Buzzer works great for breadboarding projects since it fits right into a breadboard or paperboard. 3V To 12V Piezo Active Buzzer is a small 12mm round speaker that operates around the audible 2kHz range. You can use these speakers to create simple music or user interfaces. This is not a true piezoelectric speaker but behaves similarly. Instead of a piezoelectric crystal that vibrates with an electric current, this tiny speaker uses an electromagnet to drive a thin metal sheet. That means you need to use some form of alternating current to get sound. The good news is that this speaker is tuned to respond best with a square wave (e.g. from a microcontroller).We have also 3 pins Passive Buzzer, Piezo Passive Buzzer, Piezo Buzzer Alarm Speaker, etc.
Features of 3V To 12V Piezo Active Buzzer:

Piezo sounders contain a piezoelectric vibration plate (also known as a piezo element) within a molded case.
Sound is emitted when a voltage is applied and the piezo element inside the case vibrates.
Piezo buzzers generally use less current.
Have a higher sound output and a wider operating voltage.
Buzzers and Sounders can also be split into Audio Indicators and Audio Transducers.

Specifications of 3V To 12V Piezo Active Buzzer:

Voltage: 3v~12v
Size: 12MM
Material: COPPER PLATES
Colour: BLACK
Body Material: PLASTIC
Diameter: 10MM
Resonant Frequency (kHz): 4.0±0.5
Shape: ROUND
Sound Output: 80dB
Storage Temperature (℃): -30~+85

Package Includes:

1 x 3V To 12V Piezo Active Buzzer
