MASTECH MS6813 is a handheld network cable tester. This MS-6813 cable tracker is ideal for Coaxial Cable (BNC), UTP and STP Cable installation, measurement, maintenance or inspection. This multifunction network wire tracker locator also offers a fast and convenient way of testing telephone line modes greatly simplifies telephone line installation and maintenance. A very useful detector device that allows to judge continuity of cables and wires, track cables, wires, metal pipes and diagnose the breakpoint. MS6813 cable tracer kit consists of two devices - toner and probe. The toner is also network cable tester with shield integrity test and debugs mode.Features Of MASTECH MS6813 Multi-function Telephone Line Tester Detector Tracker RJ45 RJ11 COAX:
Testing Coaxial Cable (BNC).
Twisted-wire-pair cables (RJ45): 10Base-T, T568A, T568B, Token Ring.
Testing Cable's Shield Integrity.
Judge Continuity of the Cables or Wires
Track the cables or wires, and diagnose the break Point
Receive the tone signal on the cables or wires(telephone line)
Identify the state in the working telephone line(clear, ringing, busy)
Send a Single Solid or a Dual Alternating Tone to the Target Cables or Wires
Specifications Of Mastech MS6813 Signal Probe Link Tester Network Cable Tracer:
Send audio signal frequency: 4KHz
Receive frequency range: 100 to 300KHz
Transmitter power supplied by: 1 * DC 9V 6F22 battery
Receiver power supplied by: 1 * DC 9V 6F22 battery
Operating temperature: 0 to 50 Celsius degree
Certificate: CE
Transmitter size: 22 * 8.3 * 4.3cm/ 8.6'' * 3.2'' * 1.7''
Transmitter weight: 263g/ 9.2oz
Receiver size: 15.5 * 3.3 * 2.2cm/ 6.1'' * 1.3'' * 0.8''
Receiver weight: 45g/ 1.5oz
Package size: 25 * 13.7 * 5.5cm/ 9.8'' * 5.4'' * 2.1''
Package weight: 525g/ 18.5oz
Package Includes:
1 x MS6813T cable tracker (Transmitter)
1 x MS6813R cable tracker (Receiver)
1 x English user manual
