A4988 DRV8825 Compatible NEMA 17 Stepper Motor With GT2 Compatible Pulley

Rs.735
SKU: 7212
Availability : In Stock Pre order Out of stock
People are viewing this right now
sold in last hours

Description

NEMA17 6 Wire Bipolar Stepper Motor NEMA17 Stepper Motor NEMA 17 Stepper Motorus very useful in the various application especially which demands low speed with high precision. Many machines such as 3D Printers, CNC Router and Mills, Camera Platforms, XYZ Plotters, etc. Nema17 6 wire Bipolar Stepper Motor is High precision 6-wire bipolar stepper motor, size in Nema 17, 1.8 deg. step angle (200 … It is one of most parameters for the stepper motor). The motor was specified to have a max current of 1A so that it could be driven easily with an  A4988 or drv8825 and a wall adapter.Specifications NEMA 17 Stepper Motor With GT2 Compatible Pulley :

Step Angle: 1.8°
Phase Current: 1.3A
Max. Temperature Rise: 80℃ (rated current, 2 phase on)
Operating Temperature: -20℃~+70℃
body length 49 mm
width / height 42 mm
The total length of 68 mm
weight 0.40 kg
