Description
Mini DC-DC buck adjustable voltage converter is a DC / DC converter input 4.75V - 23V output 1V - 17 V (buck mode, input must be greater than 1.5 V output). Differs in compact size and high efficiency.
The mini DC-DC step-down adjustable voltage converter, thanks to the high conversion frequency of 340 KHz, allows you to get a large current in the load up to 1.8A continuously, up to 3A for a short time with a small size of the converter.
The mini DC-DC buck voltage converter can be used as a high-efficiency switching power supply with a small footprint.
A compact variable resistor allows you to adjust the required output voltage.
Mini DC-DC buck voltage converter is recommended for 2s - 5s lithium polymer batteries.
Mini 360 DC to DC Step Down Buck Converter Module Feature:
- Step Down Module
- Condition: New
- Type: Mini-360
- Non-isolated step-down
- Input voltage: 4.75V-23V
- Output voltage: 1.0V-17V
- Current output: peak 3A, 1.8A long time
- Synchronous rectification
- Size: approx. 17 x 11 x 3.8mm
- Transfer efficiency: 96% ( highest)
- Swtiching frenquency: 340KHz
- Output ripple: 30mV(no-load)
- Load regulation: ±0.5>
- Voltage regulation: ±2.5>
- Operating temperature: -40~+85
Applications:
- Main Application of Mini DC-DC Buck Voltage Converter:
- power supply of mobile devices,
- communication equipment,
- toys
- power supply of other electronics,
Package Includes:
- 1 x Mini 360 DC to DC Step Down Buck Converter Module
