MG945 Metal Gear Servo Motor 180 Degree

Rs.830
SKU: MG945
Availability : In Stock Pre order Out of stock
People are viewing this right now
sold in last hours

Description

MG945 Towerpro Digital Metal Servo 12KG High torque MG945 is for 1/8 buggy  monster and many RC model. It is low cost of digital servo with export quality and great  servo for just about any application.

Specifications MG945 Metal Gear Servo Motor 180 Degree:

  • Weight: 55g
  • Dimension: 40.7×19.7×42.9mm
  • Stall torque: 10kg/cm (4.8v); 12kg/cm (6v)
  • Operating speed: 0.23sec/60degree (4.8v); 0.2sec/60degree (6.0v)
  • Operating voltage: 4.8 ~ 6.6v
  • Temperature range: 0- 55deg
  • Gear Type: Metal gear
  • Dead band width: 1us
  • Power Supply: Through External Adapter
  • servo wire length: 32cm
  • Current draw at idle 10MA
  • No load operating current draw 170MA
  • Stall current draw 1200MA
  • Servo Plug: JR (Fits JR and Futaba)
  • servo arms &screws included and fit with Futaba servo arm
  • It’s universal “S” type connector that fits most receivers, including Futaba, JR, Hitec ,GWS, Cirrus, Blue Bird, Blue Arrow, Corona, Berg, Spektrum.

Package Includes:

1 x MG945 Metal Gear Servo Motor 180 Degree
