4-axis MACH3 module is used to receive data from the computer's LPT parallel communication port to receive commands and control other actuators such as reading data from the sensor, outputting the motor control pulse, and activating the water pump relay.
The MACH3 axis module is designed to control 4 axes of X, Y, Z, A and a relay jack output, 5 input sensor readouts and spindle control pulse output port (machining head). The circuit uses the USB port for direct power supply, All output control ports are opto isolated and are buffered for the most stable signal.
Specifications
- - Power supply: 5-12VDC
- - Supports 4 axis control X, Y, Z, A
- - Use a relay to generate PWM pulses used to control spindle
- - Analog output (0 - 10V) connected to a spindle speed control inverter
All outputs are opto-isolated and buffer ic isolated to ensure signal stability
Package Includes:
- 1 x Mach3 CNC Breakout Board 5 Axes CNC Breakout Board
