Best Online Shopping website for LM2902N 14 Pin Differenial OP AMP IC . Here you get best LM2902N 14 Pin Differenial OP AMP IC which is similar to LM324 Ic and also named as op amp ic in reasonable price in in Gujranwala, Karachi, Lahore, Islamabad, Rawalpindi, Peshawar, Multan, Quetta , Faisalabad and all over Pakistan.An Operational Amplifier or op-amp is a voltage amplifying device. It is a high-gain electronic voltage amplifier with a differential input and usually a single-ended output. Quadruple operational amplifier are a device consist of four independent high-gain frequency-compensated operational amplifiers that are designed specifically to operate from a single supply or split supply over a wide range of voltages.
Features:
2-kV ESD Protection for:
LM224K, LM224KA
LM324K, LM324KA
LM2902K, LM2902KV, LM2902KAV
Wide Supply Ranges
Single Supply: 3 V to 32 V
(26 V for LM2902)
Dual Supplies: ±1.5 V to ±16 V
(±13 V for LM2902)
Low Supply-Current Drain Independent of
Supply Voltage: 0.8 mA Typical
Common-Mode Input Voltage Range Includes
Ground, Allowing Direct Sensing Near Ground
Low Input Bias and Offset Parameters
Input Offset Voltage: 3 mV Typical
A Versions: 2 mV Typical
Input Offset Current: 2 nA Typical
Input Bias Current: 20 nA Typical
A Versions: 15 nA Typical
Differential Input Voltage Range Equal to
Maximum-Rated Supply Voltage:
32 V (26 V for LM2902)
Open-Loop Differential Voltage Amplification:
100 V/mV Typical
Internal Frequency Compensation
Pin Configuration:
Datasheet:
datasheet for LM2902N
Package Include:
1x LM2902N OP AMP IC
