This is Micro USB port-based Arduino Nano which is the latest model of Arduino nano which is operating on 5V and 16Mhz crystal frequency with atmega328p Micro-controller. The Arduino Nano is a small, complete, and breadboard-friendly board based on the ATmega328 (Arduino Nano 3.x) It has more or less the same functionality as the Arduino Uno but in a different package. Arduino Nano lacks only a DC power jack and works with a Mini-B USB cable instead of a standard one.
Specifications Of Arduino Nano With Micro USB Port:
Microcontroller: ATmega328 (arduino nano).
Operating Voltage (logic level): l5 V.
Input Voltage (recommended): 7-12 V.
Input Voltage (limits): 6-20 V.
Digital I/O Pins: 14 (of which 6 provide PWM output).
Analog Input Pins: 8.
DC Current per I/O Pin: 40 mA.
Flash Memory: 16 KB (ATmega168) or 32 KB (ATmega328) of which 2 KB used by the boot loader.
SRAM: 1 KB (ATmega168) or 2 KB (ATmega328).
EEPROM: 512 bytes (ATmega168) or 1 KB (ATmega328).
Clock Speed: 16 MHz.
Dimensions: 0.73" x 1.70".
Length: 45 mm.
Width: 18 mm.
Weight: 5 g.
Features Of Arduino Nano With Micro USB Port:
Automatic reset during program download
Power OK blue LED
Green (TX), red (RX), and orange (L) LED
Auto-sensing/switching power input
Small mini-B USB for programming and serial monitor
ICSP header for direct program download
Standard 0.1” spacing DIP (breadboard friendly)
Manual reset switch
Related Documents:
IC CH340G Datasheet here
IC Atmel ATmega 328 Datasheet here
Package Includes:
1 x Arduino Nano V3 Arduino Nano With Unsoldered Headers
