Kf45 Kf-45 3 Pin Power Connector 25 Amp Pcb Mount Power Connector

Rs.44
SKU: 6485
Availability : In Stock Pre order Out of stock
People are viewing this right now
sold in last hours

Description

KF45S Barrier Terminal Block 9.5mm Spacing9.5mm spacing barrier terminals with side expandable slot. The terminal accepts wire gauge of 22~12AWG. Connectors are available in black PA66 material.

Brief Data:

Voltage Rating: 300V.
Current Rating: 25A.
Wire Gauge: 22~12 AWG.
Pin Spacing: 9.5mm.
Number of Poles: 2~24 (Stackable)
Housing Material: PA66UL94V-0.
Solder Pin: Tinned Brass.
Screw: M3 Steel Nickel plated.
Mounting Type: PCB thru-hole.
Rated impulse voltage: 2KV.
