The JQX-30F electromagnetic relay is an electromechanical switch which allows low circuits to operate high current ones. This DC12VC relay is a small size, lightweight and with low coil power consumption. This relay has many advantages compared to conventional switches. For this reason, this best relay has diverse industrial and household applications.Features & Specifications Of Electromagnetic JQX-30F (T91) Coil 12VDC 240VAC/20A Relay:
Model: JQX-30F (T91)
Type: universal
Nominal coil voltage: 12 VDC
Nominal contact system voltage: 240 VAC
Contact capacity: 20 A / 240 VAC
Contact configuration: SPST - NO
Number of pins, feathers: 6
Coil power: <0.9 W
Switch-on time: 10ms max
Mounting: PCB + 2 terminals - 6.3mm auto pen
Contact resistance: <50 mOhm
Insulation resistance: > 100 MOhm / 500 VDC
Mechanical endurance of contacts: 1,000,000 times
Electrical endurance of contacts: 100,000 times
Dielectric strength between open contacts: 1000 V rms / per 1 min
Dielectric strength between coil and contacts: 1500 V RMS / per 1 min
Operating temperature: from -45°C to + 70°C
Dimensions: 32 x 27 x 28 mm
Similar products: SIEMENS T91; OMRON G7G
Applications:
Industrial and power management.
Package Includes:
1 x JQX-30F DC12VC Relay
