3w Hlk-pm01 Ac Dc 220v To 5v Step Down Power Supply Module Isolated Power Supply Module

Rs.784
SKU: 9293
Availability : In Stock Pre order Out of stock
People are viewing this right now
sold in last hours

Description

Hi-Link latest power supply module, suitable for smart home switch control device, small volume, low current, input voltage range, is the best choice of a smart home. Low ripple and low noise. Output overload short circuit protection function. High efficiency and power density. Low power consumption. 100% load test.

Features:

  • Rated input voltage: 100-240 V AC
  • Input voltage range: 90~264 V AC
  • Maximum input current: ≤ 0.2 A
  • Input inrush current: ≤ 10 A
  • Maximum input voltage: ≤ 270 V AC
  • Input slow start: ≤ 50 mS
  • Input low voltage efficiency: Vin = 110V AC, the output full load ≥ 69 %
  • Input high voltage efficiency: Vin = 220VAc, the output full load ≥ 70 %
  • Long term reliability: MTBF ≥ 100,000 H
  • No-load rated output voltage: 5 ± 0.1 V DC
  • Full load rated output voltage: 5 ± 0.2 V DC
  • Short time maximum output current: ≥ 1000 MA
  • Long time maximum output current: ≥ 600 MA
  • Voltage regulation: ± 0.2%
  • Load Regulation: ± 0.5%
  • Output ripple and noise: (MVp-p) ≤ 50 MV. -- Rated input voltage, output full load. With 20MHz bandwidth oscilloscope, the load side is tested with 10uF and 0.1uF capacitors.

Specifications:

  • Switch machine overshoot: (Rated input voltage, output plus 10% load) ≤ 5% VO
  • Output over-current protection -- Output the maximum load of 150-200% A
  • Output short circuit protection.
  • High efficiency, high power density
  • The product is designed to meet the requirements of EMC and Safety Test

Notes:

Temperature rise rule:
At room temperature, the power supply capacitor, the main transformer and other internal surface temperature rise cannot exceed 90 ℃;
Shell surface temperature rise cannot exceed 60 ℃;

Package Includes:

  • 1x HLK-PM01 AC DC 220V to 5V Step-Down Power Supply Module Isolated Power Supply Module
