Description
TypeCMP7-S-DC12V-C
Coil nominal voltage
12 V DC
Min. pick-up voltage
8.4 V DC
Control mode
monostable, 1 coil
R(coil)
160 Ω
Coil voltage rating
900 mW
Contact type
1 change-over
Contact material
Ag
Switching voltage (max.)
28 V DC , 250 V AC
Switching current (max.)
30 A
Max. switching capacity
7500 VA , 560 W
Connection
Print
Electrical lifespan
100 000 Switching cycles
Durability
1000 0000 switching cycles
Features
+ enclosure
Min. temperature
-40 °C
Max. temperature
+85 °C
Length
31.8 mm
Width
27.4 mm
Height
20 mm
Content
1 pc(s)
RoHS-compliant
Yes
Product type
PCB relay
