UT81 series handheld digital oscilloscope multimeters combine oscilloscope and digital multimeter in one. Oscilloscope measurement mode includes signal input, data processing, auto measure, waveform storage, and transfer.Multimeter mode features AC/DC voltage and current, resistance, diode, continuity, frequency, duty ratio, and capacitance.
Features:
UT81 series handheld digital oscilloscope multimeters combine oscilloscope and digital multimeter in one. Oscilloscope measurement mode includes signal input, data processing, auto measure, waveform storage, and transfer.Multimeter mode features AC/DC voltage and current, resistance, diode, continuity, frequency, duty ratio, and capacitance.
Technical specification:
Specifications | Range | UT81C |
DMM Specifications | ||
DC voltage (V) | 1000V | ±(0.8%+8) |
AC voltage (V) | 750V | ±(1%+15) |
DC current (A) | 10A | ±(1%+8) |
AC current (A) | 10A | ±(1.5%+8) |
Resistance (Ω) | 40MΩ | ±(1%+5) |
Capacitance (F) | 100μF | ±(3%+8) |
Frequency (Hz) | 10Hz~10MHz | ±(0.1%+3) |
Scope Specifications | ||
Bandwidth | 16MHz | |
Sampling rate | 80MS/s | |
Vertical accuracy | ±(5%+1) | |
Vertical sensitivity | 20mV/div~500V/div (1-2-5) | √ |
Time-base accuracy | ±(0.01%+1) | |
Time-base range | 50ns/div - 5s/div(1-2-5) | |
Features | ||
Display count | 4000 | |
Auto range | √ | |
Duty cycle | 0.1~99.9>#/td### | √ |
Diode | √ | |
Auto power off | √ | |
Continuity buzzer | √ | |
Display | 160 x 160 monochrome | √ |
Trigger types | Auto run/Normal/Single shot | √ |
Memory | 10 screens and setups | √ |
Contrast and brightness setup | √ | |
Low battery indication | √ | |
USB interface | √ | |
LCD backlight | √ | |
Input impedance for DCV | Around 10MΩ | √ |
General Characteristics | ||
Power | 1.5V battery (R6) x 4 | |
Display | 60mm x 60mm | |
Product color | Red and grey | |
Product net weight | 498g | |
Product size | 200mm x 100mm x 48mm | |
Standard accessories | Batteries, test lead, alligator clip, USB interface cable, PC software CD | |
Standard individual packing | Gift box, English manual |
Package:
1 x UT81C UNI T Handheld Digital Scope Multimeter
