UTG2062B UNI T General Function Generator

Rs.143,100
SKU: UTG2062B
Availability : In Stock Pre order Out of stock
People are viewing this right now
sold in last hours

Description

UTG2000B series can produce high precision, stable, pure and low distortion signals; provide high frequency square wave with quick rise and fall edges. Users can improve their working efficiency by using the multifunctional instrument of easy operated interface, competitive specifications and humanized graphical display.

Applications:
Designing, testing, troubleshooting, and repairing of electronic and electroacoustic devices, such as circuit and equipment testing in cellular and wireless systems, broadcasting, television and radio systems; semiconductor component testing etc.

Features:

1. 1μHz full-band resolution2. 5MHz~30MHz pulse waveform, adjustable rise/fall time
3. 14-bit/16-bit vertical resolution
4. Two equivalent-performance channels
5. Max arbitrary waveform length of 8k/16M points; 48/161
6. non-volatile waveforms storage

Technical specification:

Specifications UTG2062B
Max frequency 60MHz
Channels 2
Sampling rate 320MS/s
Waveforms Sine, square, ramp, pulse, noise, DC, arbitrary; UTG2000B only: harmonic
Working modes Output on/off, continuous, modulation, sweep, burst
Modulations AM, FM, PM, ASK, FSK, PSK, PWM, BPSK, QPSK, OSK, DSB-AM, SUM, QAM
Arbitrary Waveform
Length 8pts~16Mpts
Vertical resolution 16 bits (symbol included)
Frequency Characteristics
Sine 1μHz~60MHz
Square 1μHz~25MHz
Pulse 1μHz~20MHz
Ramp 1μHz~3MHz
Harmonic 1μHz~30MHz
Arbitrary 1μHz~15MHz
Noise 60MHz (-3dB)
Resolution 1μHz
Accuracy ±0.5ppm 25℃
First year aging rate: 1ppm
Temperature coefficient: ±0.5ppm/℃
Temperature Coeifficient  <2ppm/℃
Interfaces USB Host, USB Device, 10MHz clock source input/output
General Characteristics
Power 100V~240V ACrms, 50Hz/60Hz
Display 4.3-inch TFT LCD, WVGA (480 x 272)
Product color White and grey
Product net weight 3.2kg
Product size 265mm x 110mm x 320mm
Standard accessories BNC-BNC cable, BNC cable with alligator clips, power cord, USB interface cable
Standard individual packing Carton box

Package:

1 x UTG2062B UNI T General Function Generator
