UTG1005 UNI T Function Generator DDS

Rs.0
SKU: UTG1005
Availability : In Stock Pre order Out of stock
People are viewing this right now
sold in last hours

Description

UTG1000A function/arbitrary waveform generators adopt direct digital synthesis technology to produce accurate and stable waveform output with 1Hz resolution. Modulations such as AM, PM, FM, ASK, FSK etc. with internal or external source, linear and logarithmic sweeps and USB interface are available. The panel is ergonomically constructed for simple operation.

Applications:
Designing, testing, troubleshooting, and repairing of electronic and electroacoustic devices, such as circuit and equipment testing in cellular and wireless systems, broadcasting, television and radio systems; semiconductor component testing etc.

Features:

1. Intuitive interface design2. Single channel
3. 125MS/s sampling rate, 14-bit vertical resolution
4. Integrated analog and digital design
5. 4.3 inches TFT LCD

Technical specification:

Specifications
Model UTG1005
Channel 1
Sampling rate 125MS/s
Output frequency 5MHz
Frequency Characteristics
Sine 1μHz~5MHz
Square 1μHz~5MHz
Ramp 1μHz~400kHz
Pulse 1μHz~5MHz
Arbitrary 1μHz~1MHz
Resolution 1μHz
Accuracy Within 90 days ± 50ppm
Within 1 year ± 100ppm
18℃~28℃
Arbitrary Waveform
Vertical resolution 14 bits
Max. memory depth 16 sets of arbitrary waveforms
Others
Output standard waveform Sine, square, ramp, triangle, pulse, noise, DC, arbitrary
Output amplitude range 1mVpp~10Vpp (50Ω); 2mVpp~20Vpp (High Z)
Modulation types AM, FM, PM, PWM, ASK, FSK, PSK
Interface USB Device
General Characteristics
Power 100~240V AC, 50Hz/60Hz
Display 4.3 inches TFT LCD, WVGA (480 x 272)
Product color White and grey
Product net weight 3.2kg
Product size 165mm x 110mm x 320mm
Standard accessories USB interface cable, power cord, BNC-BNC cable
Standard individual packing Carton box

Package:

1 x UTG1005 UNI T Function Generator DDS
