FR207 diode has a cathode (-) and anode (+). In the schematic symbol, the tip of the triangle with the line on top of it is the cathode. The cathode is marked on the body of a diode by a band as shown below.
Diode polarity Current can flow from the anode to the cathode only and never from the cathode to the anode - FR207 diode is like a one way valve.
Dimensions FR207 diode
Features:
Maximum Recurrent Peak Reverse Voltage - 1000 V
Typical Junction Capacitance 40 pF
Operating and Storage Temperature Range -65...+150 °C
Specifications:
Wattage: 1W
Diode/rectifier type: DO-41
RoHS: Yes
Standard Recovery Power Rectifier
Repetitive Reverse Voltage Max, Vrrm: 50V
Forward Current Avg Rectified, IF(AV): 1A
Forward Surge Current Max, Ifsm: 30A
Forward Voltage Max, VF: 1.1V
Current Rating: 1A
Data Sheet:
https://img.filipeflop.com/files/download/Datasheet_Diodo_FR201-FR207.pdf
Package Includes:
10 x FR207 diode
