PL-05N/2 Inductive Proximity Sensor Switch NPN NO for FOTEKABS plastic shell, angular column type, 3 wire system. When proximity switch is close to some target object, it will send out control signal. Power supply inverted connecting protection, short circuit protection, non-contact detecting device. Used widely in the machine tool industry, frequency counters, and another automatic control system.
Properties .
PL-05N
Square Type
Sensing distance : 5mm
Operating voltage : DC10-30V
Response frequency : 800Hz
Output method : NPN, 150mA load
Hysteresis : <10% of sensing distance
Protection degree : IP67
Working temperature/Hum : -20 ~ 80C, 35%~90%RH
Body dimension : 30.5×17.9×10.2mm, LxWxH
Screw hole : 3.2mm, Pitch : 10.5mm
Wire length : 200cm
with CE safety
